GCMS-QP2020 NX Gas Chromatograph Mass Spectrometer

Name: GCMS-QP2020 NX Gas Chromatograph Mass Spectrometer
Brand: TOSHVIN ANALYTICAL PVT LTD
Price: 500000-10000000 INR
Availability: InStock

Price 500000-10000000 INR/ Ton

Get a Price/Quote

MOQ : 1 Piece

GCMS-QP2020 NX Gas Chromatograph Mass Spectrometer Specification

Specimen Size
1 L to 100 L (liquid injection)

Accuracy
0.005 u (m/z calibration)

Response Time
<1 sec (scan rate up to 10,000 u/sec)

Gas Pressure
Carrier gas pressure up to 600 kPa

Temperature
Oven temperature up to 450C

Power Supply
AC 220V, 50/60Hz

Hardness
N/A (non-applicable for analytical instruments)

Operating Voltage
220V AC

Test Range
m/z 1.5 to 1000

Mounting Type
Bench-top

Measuring Range
m/z 1.5 to 1000

Frequency
50/60 Hz

Equipment Type
Gas Chromatograph Mass Spectrometer

Number of Specimens
Automatic sample changer (12/30 positions)

Resolution
Unit mass resolution at m/z 100

Interface Type
LAN, USB, Serial

Features
High Sensitivity, Fast Scan, Eco-mode, Automated Tuning, Conservation of Power

Automation Grade
Fully Automated

Application
Chemical Analysis, Environmental Testing, Food Safety, Forensic Analysis

Display Type
Graphical LCD, PC Display

Humidity
20% to 80% RH (Non-condensing)

Max Height
520 mm

Port Size
1/16 inch standard capillary fitting

Usage
Laboratory & Industrial

Capacity
Up to 30 sample vials

Machine Weight
About 80 kg

Test Speed
0.1 to 10 mL/min (Programmable) for GC flow rate

Test Width
Standard 0.25mm capillary column internal diameter

Test Stroke
Configurable via software, typically 2~30 mm sample size

Control Mode
Touch-Screen Keypad, PC-Enabled Software

Inlet Type
Split/Splitless and PTV available

Scan Speed
Up to 20,000 u/sec

Ion Source
Electron Impact (EI) and Chemical Ionization (CI)

Dimensions
520 × 420 × 490 mm (W × D × H)

Carrier Gas Types
He, H2, N2 support

Sensitivity
1.5 fg or less of octafluoronaphthalene

Noise Level
<55 dB

Software
GCMSsolution Workstation (Windows Supported)

Mass Analyzer Type
Quadrupole

Column Oven Capacity
Accommodates up to 3 columns

Data Storage
High capacity internal and external storage

Vacuum System
Dual Rotary & Turbo Molecular Pump

GCMS-QP2020 NX Gas Chromatograph Mass Spectrometer Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
10 Pieces Per Month

Delivery Time
1 Months

About GCMS-QP2020 NX Gas Chromatograph Mass Spectrometer

We are engaged in rendering a wide array of GCMS-QP2020 NX Gas Chromatograph Mass Spectrometer. It is used for the bioanalysis of body fluids to detect the alcohols and other drugs such as hypnotics, anesthetics etc. In addition to this, provided instrument is able to detect the pollutants as well as metabolites in serum. GCMS-QP2020 NX Gas Chromatograph Mass Spectrometer is easy to separate the chemical mixture and passed the molecule in a reliable manner.

High Performance Mass Spectrometry

Equipped with quadrupole mass filtering and dual ionization options (EI and CI), the GCMS-QP2020 NX achieves unit resolution across a wide m/z range (1.5-1000). Its rapid scan speed and sensitivity down to femtogram levels make it suitable for trace-level detection, delivering precise and reliable results for both routine and advanced analytical tasks.

User-Friendly Automation & Software Integration

This model features a touch-screen keypad, graphical LCD, and intuitive PC interface with GCMSsolution Workstation, streamlining control and data management. The automated sample changer increases throughput, allowing up to 30 samples per sequence. Programmable GC flow rates and oven parameters guarantee flexibility for different analytical protocols.

Versatile Applications for Modern Laboratories

Engineered for chemical analysis, forensic investigations, food safety and environmental testing, the GCMS-QP2020 NX adapts to a wide variety of industries. Its robust construction, low noise (<55 dB), high column capacity, and eco-friendly power conservation make it an asset for fully automated, high-volume laboratory environments.

FAQ's of GCMS-QP2020 NX Gas Chromatograph Mass Spectrometer:

Q: How can the GCMS-QP2020 NX improve laboratory productivity?

A: By supporting fully automated sample changing for up to 30 vials, fast scan speeds of up to 20,000 u/sec, and programmable flow rates, the GCMS-QP2020 NX streamlines sample throughput, reduces turnaround time, and increases the efficiency of routine and complex analyses alike.

Q: What sample sizes and types can this GC-MS system accommodate?

A: The instrument is compatible with liquid injection sample sizes ranging from 1 L to 100 L and accepts up to 30 vials in its automatic sample changer, making it suitable for a wide variety of sample types and testing protocols.

Q: When is it beneficial to use Electron Impact (EI) versus Chemical Ionization (CI) mode?

A: Electron Impact (EI) mode is ideal for generating reproducible fragmentation patterns in most organic compounds, aiding structural elucidation. Chemical Ionization (CI) mode provides softer ionization for thermally sensitive or fragile molecules, often delivering clearer molecular ions for more accurate mass measurements.

Q: Where can the GCMS-QP2020 NX be installed and utilized effectively?

A: Designed as a bench-top model with a compact footprint, this instrument is suitable for installation in laboratories-industrial, academic, or governmental-focused on chemical, food safety, forensic, or environmental testing.

Q: What supporting gases can be used, and how is carrier gas pressure managed?

A: The GCMS-QP2020 NX supports helium, hydrogen, and nitrogen as carrier gases, with carrier gas pressure control up to 600 kPa. The dual rotary and turbo molecular vacuum pump system maintains stable operational conditions regardless of the chosen carrier gas.

Q: How is data managed and stored for analysis and reporting?

A: The system offers both high-capacity internal and external data storage options, with seamless data acquisition and analysis through GCMSsolution Workstation software. This setup ensures secure and efficient handling of large volumes of analytical data for subsequent processing or reporting.
